Vertiv NetSure 502 Full DC Power System

Additional information

Manufacturer

Your Price: $0.00
Add to Quote

Tempest Makes It Simple

The Vertiv NetSure 502 Full DC Power System is a compact -48 volt 600 A DC power solution, features an advanced control unit, up to (17) positions for 2000 W high-efficiency eSure rectifiers, and a single or dual row distribution cabinet. [Spec #582136800].

NetSure 502 Series: Traditional Flexible Configuration Indoor DC Power

The NetSure 502 DC Full DC Power Solution is a flexible system capable of providing DC power through the use of 2000 W rectifiers and a variety of output distribution options. The NetSure 502 is available in both 19″ and 23″ rack-mount configurations. This highly flexible DC power system is available in bulk output shelves, integrated distribution shelves or externally mounted distribution panel systems. These alternatives are optimal for rack-mounting in any building, shelter or cabinet installation.

  • -48 volt 120 A DC
  • Capacity: 18 – 28.8 kW, 40   600 A
  • High efficiency: 96.5% efficient eSure rectifiers NetSure™ rectifiers are designed to operate from -40°C to +80°C, providing a minimum 1750 W output at 65°C
  • Supports Ethernet, SNMP V2 & SNMP V3, ModBus and RS485 communication interfaces
  • vertiv-netsure-500 SeriesSelectable AC Input: 120 VAC, 208 to 240 VAC
  • Battery Management Capability
  • ECO Energy Savings Mode
  • NEBS Level 3 compliance and UL Listed
  • Minimize total cost of ownership with high efficiency eSure rectifiers
  • Achieve energy savings with ECO mode, even at low loads
NetSure 502 Full DC Power System
NetSure 502 Integrated DC Power System
